Introduction

Analysis of a mouse heart gene expression data set with 2 vs 2 samples.

source("../code/gdash_lik.R")
Loading required package: EQL
Loading required package: ttutils
Loading required package: SQUAREM
Loading required package: REBayes
Loading required package: Matrix
Warning: package 'Matrix' was built under R version 3.4.4
Loading required package: CVXR

Attaching package: 'CVXR'
The following object is masked from 'package:stats':

    power
Loading required package: PolynomF
Loading required package: Rmosek
Loading required package: ashr
counts.mat = read.table("../data/smemo.txt", header = T, row.name = 1)
counts.mat = counts.mat[, -5]
counts = counts.mat[rowSums(counts.mat) >= 5, ]
design = model.matrix(~c(0, 0, 1, 1))
dgecounts = edgeR::calcNormFactors(edgeR::DGEList(counts = counts, group = design[, 2]))
v = limma::voom(dgecounts, design, plot = FALSE)
lim = limma::lmFit(v)
r.ebayes = limma::eBayes(lim)
p = r.ebayes$p.value[, 2]
t = r.ebayes$t[, 2]
z = -sign(t) * qnorm(p/2)
fit.locfdr <- locfdr::locfdr(z)

fit.qvalue <- qvalue::qvalue(p)
x = lim$coefficients[, 2]
s = x / z
fit.cash <- gdash(x, s)
fit.ash <- ashr::ash(x, s, mixcompdist = "normal", method = "fdr")
x.plot <- seq(-10, 10, length = 1000)
gd.ord <- 10
hermite = Hermite(gd.ord)
gd0.std = dnorm(x.plot)
matrix_lik_plot = cbind(gd0.std)
for (i in 1 : gd.ord) {
  gd.std = (-1)^i * hermite[[i]](x.plot) * gd0.std / sqrt(factorial(i))
  matrix_lik_plot = cbind(matrix_lik_plot, gd.std)
}
y.plot = matrix_lik_plot %*% fit.cash$w * fit.cash$fitted_g$pi[1]

method.col <- scales::hue_pal()(5)
setEPS()
postscript("../output/paper/mouseheart.eps", height = 5, width = 7)

hist(z, prob = TRUE, main = "", xlab = expression(paste(z, "-scores")), cex.lab = 1.25, breaks = 20)
lines(x.plot, y.plot, col = method.col[5], lwd = 2)
lines(x.plot, dnorm(x.plot), col = "orange", lty = 2, lwd = 2)
lines(x.plot, dnorm(x.plot, fit.locfdr$fp0[3, 1], fit.locfdr$fp0[3, 2]) * fit.locfdr$fp0[3, 3], col = method.col[3], lty = 2, lwd = 2)

text(-2.7, 0.2, "N(0,1)", col = "orange")
arrows(-2.1, 0.2, -1.2, 0.195, length = 0.1, angle = 20, col = "orange")

text(-4.4, 0.13, bquote(atop(" locfdr empirical null", .(round(fit.locfdr$fp0[3, 3], 2)) %*% N(.(round(fit.locfdr$fp0[3, 1], 2)), .(round(fit.locfdr$fp0[3, 2], 2))^2))), col = method.col[3])
arrows(-2.9, 0.13, -2, 0.125, length = 0.1, angle = 20, col = method.col[3])

text(4.2, 0.08, "cashr", col = method.col[5])
arrows(3.7, 0.08, 2.8, 0.075, length = 0.1, angle = 20, col = method.col[5])

dev.off()
quartz_off_screen
                2
